Docker images for TensorFlow and PyTorch running on Ubuntu 18.04 for Arm are now available. This article explains the details to build and use the Docker images for TensorFlow and PyTorch on Arm.
TensorFlow and PyTorch are two of the most popular machine learning frameworks. Both are seeing increased usage on Arm, ranging from smaller systems like the Raspberry Pi to larger systems for server and high-performance computing (HPC). Even though there is some support for AArch64 in packages already, users may want to compile everything from source. Reasons include using specific tools, targeting a different runtime environment, and experimenting with performance improvements from underlying libraries. Arm continues work to make ML on Arm well supported and to contribute optimizations to achieve the highest possible performance.
We hope these Docker images and the recipes to create them will be helpful for anybody looking to use TensorFlow and PyTorch on AArch64.
Scripts to build an Ubuntu 18.04 based Docker image are available from the Arm tool-solutions repository on GitHub.
The finished TensorFlow and PyTorch images contain:
The TensorFlow image also contains a Python3 environment built from CPython 3.7 containing:
The PyTorch image also contains a Python3 environment built from CPython 3.8 containing:
To build and run the Docker images make sure the machine being used is Arm AArch64.
$ uname -m aarch64
Any AWS EC2 instance powered by Graviton can be used to try out the images, including A1, T4g, M6g, C6g, or R6g. The TensorFlow and PyTorch images are significantly faster to build and run on Graviton2. Another thing to keep in mind is that builds done on Graviton2 will be optimized for the Neoverse-N1 and will not work on AWS A1 instances.
Docker for Linux is recommended. Instructions on how to install Docker are available for various Linux distributions on the install page.
The summary to install git and Docker on Ubuntu for a username (ubuntu) is the following:
$ sudo apt update $ sudo apt upgrade -y $ curl -fsSL get.docker.com -o get-docker.sh && sh get-docker.sh $ sudo usermod -aG docker ubuntu ; newgrp docker $ docker run hello-world
Similar steps can be used for other Linux distributions.
Start by cloning the repository. Install git if needed.
$ git clone https://github.com/ARM-software/Tool-Solutions.git
To use TensorFlow change to the tensorflow-aarch64/ directory:
$ cd Tool-Solutions/docker/tensorflow-aarch64
For PyTorch change directory to the pytorch-aarch64 directory:
$ cd Tool-Solutions/docker/pytorch-aarch64
Each framework has a five stage Dockerfile so incremental progress can be saved and reused as needed.
The build.sh script builds images and has a help flag to review the options. The build-type flag is used to specify a specific set of images to build.
Look at the scripts and directory to see the details of the build steps. These can be modified as needed.
To build all images use:
$ ./build.sh --build-type full
The default for TensorFlow is TensorFlow 1. To build TensorFlow 2 use the command-line option --tf_version 2. The images are tagged with -v1 or -v2 depending on the selected version of TensorFlow.
TensorFlow can optionally be built with oneDNN, using the '--onednn' or '--dnnl' flag. Without the '--onednn' flag, the default Eigen backend of Tensorflow is chosen. The BLAS backend for oneDNN can also be selected using the '--onednn' or '--dnnl' flags. Use -onednn reference' for the C++ reference kernelsand '--onednn openblas' for OpenBLAS.
Building TensorFlow is prone to running out of memory, but the bazel_memory_limit flag can be used to avoid exhausting available memory.
For example, to build TensorFlow 2 successfully on a machine with 32GB of memory put a limit such as:
$ ./build.sh --build-type full --tf_version 2 --onednn --bazel_memory_limit 30000 --jobs 16
Once the images are built use the docker tag and push commands to save them in your favorite image repository. I use Docker Hub to save the images. Substitute your Docker ID when tagging the images.
$ docker tag tensorflow-v2armpl jasonrandrews/tensorflow-v2armpl $ docker login (login with username and password) $ docker push jasonrandrews/tensorflow-v2armpl
Next, let us see how to run the images.
MLCommons (MLPerf) are included in both TensorFlow and PyTorch images.
On any AArch64 machine with docker installed use the following commands to run a benchmark.
$ docker pull jasonrandrews/tensorflow-v2armpl $ docker tag jasonrandrews/tensorflow-v2armpl tensorflow-v2armpl $ docker run -it --init tensorflow-v2armpl
Refer to the MLPerf GitHub area for more information on how to download datasets and models. Examples scripts are provided in the $HOME directory of the final image.
To run resnet50 on ImageNet min-validation dataset for image classification using TensorFlow:
$ export DATA_DIR=${HOME}/CK-TOOLS/dataset-imagenet-ilsvrc2012-val-min $ export MODEL_DIR=$(pwd) $ ./download-model.sh $ ./download-dataset.sh ... output omitted at the prompt select option 1: 0) imagenet-2012-val-min-resized Version 2012 (476be5741f52384f) 1) imagenet-2012-val-min Version 2012 (60cb8b2218445c36) 2) imagenet-2012-val Version 2012 (14db79a136d98dd4) 3) dataset-imagenet-preprocessed-using-tensorflow (fac1d0d5f4e69a85) 4) dataset-imagenet-preprocessed-using-pillow (a6a4613ba6dfd570) 5) dataset-imagenet-preprocessed-using-opencv (4932bbdd2ac7a17b) Please select the package to install [ hit return for "0" ]: 1 ... more output omitted $ cd ./inference/vision/classification_and_detection $ ./run_local.sh tf resnet50 cpu
To run resnet34 on coco dataset for object detection using PyTorch pull the image and run.
$ docker pull jasonrandrews/pytorch $ docker tag jasonrandrews/pytorch pytorch $ docker run -it --init pytorch
$ export DATA_DIR=${HOME}/CK-TOOLS/dataset-coco-2017-val $ export MODEL_DIR=$(pwd) $ ./download-model.sh $ ./download-dataset.sh $ cd ./inference/vision/classification_and_detection $ ./run_local.sh pytorch ssd-resnet34 cpu
Set the environment variable MKLDNN_VERBOSE=1 to verify the build uses oneDNN when running the benchmarks.
Docker images for TensorFlow and PyTorch on AArch64 are now available on Docker Hub to get and running quickly. The images use different tags to capture the build options previously described for using various libraries. The instructions reviewed also enable users to build custom images for these machine learning frameworks. We welcome any feedback to make them easier to use or to increase performance. Please file any issues in GitHub or open a pull request if you have ideas for improvement. Another good place to look for help is the Getting started with AWS Graviton project.
