Performance improvement of XGBoost and LightGBM when deploying on AWS Graviton3

Masoud Koleini
Masoud Koleini
October 21, 2022
5 minute read time.

XGBoost (eXtreme Gradient Boosting) is an open-source machine learning library under Gradient-Boosting Decision Tree (GBDT) framework. XGBoost is used to solve regression and classification problems in data science using machine learning. And the tasks can be distributed over a cluster of machines for faster training and inference. For instance, XGBoost4J-Spark is a project for integrating XGBoost with Apache Spark.

LightGBM (Light Gradient Boosting Machine) is another open-source GDBT-based tool developed by Microsoft, mostly known for more efficient training compared to XGBoost. Similar to XGBoost, LightGBM training can be distributed over a cluster of nodes and keeps the cost of the task distribution low by reducing the communication between the nodes.

This blog compares the performance of XGBoost and LightGBM running on several AWS instances. These instances include types C5 (Skylake-SP or Cascade Lake), C6i (Intel Ice Lake), C6g (AWS Graviton2), and C7g (AWS Graviton3) and with the size of 12xlarge. The instances are all equipped with 48 vCPUs and 96GB memory.

AWS Graviton3: the 3rd generation of Graviton processor family

AWS Graviton2 processors are the second generation of the processors designed by AWS using Arm Neoverse cores, providing extensive price-performance improvements for different workloads over x86 instances in Amazon EC2. AWS Graviton3 are the 3rd generation of the Graviton processor family, delivering up to 25% higher compute performance over the 2nd generation. The performance for specific computations can be 2 to 3 times better, for instance for floating point and cryptography operations, and CPU-based machine learning applications with bfloat16 support. Graviton3 support for DDR5 has increased memory bandwidth by up to 50% compared to the instances with DDR4 support.

Benchmark environment

Benchmark Tool

XGBoost is integrated in scikit-learn, a popular machine library for Python. We use scikit-learn_bench for benchmarking XGBoost, and for benchmarking LightGBM with minor modifications. The benchmark tool and the parameters are passed in a configuration file. Sample configuration files are located inside the `config` directory on the repository. The benchmarks use Python 3.10.4 and the following versions of Python libraries:

  1. XGBoost: 1.6.2
  2. LightGBM: 3.3.2
  3. scikit-learn: 1.1.2

For the XGBoost, we run the benchmarks for the following datasets:

  1. Airline (binary classification)
  2. Higgs (binary classification)
  3. MSRank (multi-class classification)

For the LightGBM, we represent the results for the Airline and Higgs datasets.

The parameters used for the benchmarks are as follows:

tree-method (for XGBoost) hist
learning-rate 0.1
max-depth 8
max-leaves 256
n-estimators (number of estimators) 100

The `hist` tree method for XGBoost is like how LightGBM works and increases the training speed. The number of estimators is set to 100, which is the default value for XGBoost and LightGBM libraries. The number of threads is set to the number of vCPUs available on the instances, which is 48 for 12xlarge instances.

Performance comparison

XGBoost training performance

The following chart shows the training time for the three datasets and on different instance types. The results show Graviton3 instances have up to 52% training time improvement over C5, 36% improvement over C6i, and 37% improvement over Graviton2.

XGBoost Training timeFigure 1. XGBoost training time comparison

The following table shows the XGBoost training times for Airline, Higgs, and MSRank datasets.

Training time     c5.12xlarge      c6i.12xlarge    c6g.12xlarge     c7g.12xlarge
Airline 156.7542863 117.0082541 116.0416869 76.4209646
Higgs 18.89056222 14.33615984 14.11944058 9.149896008
MSRank 21.16431952 17.23972275 17.74064451 11.17478875

XGBoost inference performance

Figure 2 shows the inference time for the three datasets and on different instance types. The results show Graviton3 instances have up to 45% inference time improvement over C5, 26% improvement over C6i, and 32% improvement over Graviton2.

XGBoost Inference timeFigure 2. XGBoost inference time comparison

The following table shows the XGBoost inference times for the three datasets.

Prediction time c5.12xlarge c6i.12xlarge c6g.12xlarge c7g.12xlarge
Airline 3.872979737 2.844810675 3.137031317 2.147960264
Higgs 0.522402984 0.372625213 0.425959238 0.29535643
MSRank 0.303822537 0.225266151 0.243390166 0.166838843

LightGBM training performance

Figure 3 shows the training time for Airline and Higgs datasets, and on different instance types. The results show Graviton3 instances have up to 53% training time improvement over C5, 42% improvement over C6i, and 41% improvement over Graviton2.

LightGBM Training timeFigure 3. LightGBM training time comparison

The following table shows the LighttGBM training times for the Airline and Higgs datasets.

Training time c5.12xlarge c6i.12xlarge c6g.12xlarge c7g.12xlarge
Airline 92.7331301 72.38613732 67.94223656 43.12893921
Higgs 15.230757 12.40288175  12.0835368 7.17597144

LightGBM inference performance

Figure 4 shows the training time for the two datasets and on different instance types. The results show Graviton3 instances have up to 39% improvement over C5, 31% improvement over C6i, and 31% improvement over Graviton2.

LightGBM Inference timeFigure 4. LightGBM inference time comparison

The data for the chart in Figure 4 comes from the following table, showing inference times for LightGBM and for the Airline and Higgs datasets:

Prediction time c5.12xlarge c6i.12xlarge c6g.12xlarge c7g.12xlarge
Airline 6.5264758 5.757308737 6.026721292 4.610307491
Higgs 0.76227941 0.677829095 0.674827518 0.464917262

Benchmark considerations

scikit_learn_bench by default patched Scikit-learn using Intel(R) Extension for Scikit-learn to optimize ML performance on Intel processors with SSE2, AVX, AVX2, and AVX512 support. However, Gradient Boosting algorithms are not supported by the patch at the time of the publication of this blog.

Intel offers oneAPI Data Analytics Library (oneDAL) to accelerate ML algorithms on Intel machines. However, it requires code changes and conversion from standard XGBoost and LightGBM models to OneDAL. We have not converted and tested any of these models using OneDAL as part of this exercise.

Conclusion

XGBoost benchmarks show that Graviton3 instances outperform Graviton2 and x86 counterparts for the three datasets selected for performance analysis (Airline, Higgs, and MSRank). In some cases, Graviton3 outperforms x86 by up to 50%. Similar performance enhancement was demonstrated for LightGBM and for the two datasets of Airline and Higgs, for both the training and inference operations.

Visit the AWS Graviton page for customer stories on adoption of Arm-based processors. For any queries related to your software workloads running on Arm Neoverse platforms, feel free to reach out to us at sw-ecosystem@arm.com.

More workload blogs

References:

Medium blog post: XGBoost Algorithm: Long May She Reign!
Neptune blog post: When to Choose CatBoost Over XGBoost or LightGBM
