How to debug: CoreSight basics (Part 2)

Debug Port

Every DAP requires a Debug Port (DP). This is the master device, and implements the external interface. Debug ports supporting both JTAG and optimized 2-pin Serial Wire interface can be licensed from ARM.

The debug port provides:

• always-on connection for the debugger
• debug fault and status reporting
• power and reset request interface

Debug port accesses from the external debugger are performed as 32 bit (word) read or write transactions, targeting either DP registers, or Access Port (AP) registers. Multiple Debug ports (usually in multiple packages) can be addressed from a single external debug agent using:

• daisy chained JTAG scan chain
• star topology JTAG scan chain
• multi-drop serial wire

Access Port

Each DAP contains between 1 and 256 Access Ports (APs). The APs are controlled by the DP in response to external commands. Most APs implement a master port which interfaces to an on-chip standard bus interface. Memory APs exist for memory-mapped interfaces such as APB, AHB and AXI interconnects. A JTAG-AP can be used to interface the DAP to a traditional JTAG TAP controller. Customized access ports can also provide a simple interface to dedicated chip-level debug logic.

Memory APs provide the following features:

• Target address register
• Read or write to target address
• Bus error reporting
• Transaction in progress status
• Address incrementor (to accelerate block read/write operations)
• Access control mechanisms
• Information about connected debug components
• Perform access appearing as system master, or external debug agent.

DAP Address Space

Any individual memory mapped address in system memory might require several accesses to enable the correct path, and requires more than simply the target address in the on-chip memory map:

• DP Identifier: The debug agent might support concurrent access to more than one DAP.
• AP Select: The target AP must be selected by writing to a register in the DP.
• TAR Select: The target address must be set by writing to a register in the AP. Each AP can have a unique view of some or all of the memory mapped components in the target system.
• Data Access: Once all the addresses necessary for a DAP access to the system are set, a request to the AP can initiate the on-chip access as either a read or a write.
• Read Data retrieval: Although the on-chip access will now proceed, the debugger must perform another access to the DAP in order to retrieve the data value. This need not result in a second on-chip access.

When an access fails for some reason, the debugger is able to identify the failure. Usually the debugger can re-try the access and recover from simple errors on the interface.

Debug Memory Map Views

Both externally hosted debug agents and on-chip debug agents (for example a debug monitor) require access to debug components. Within CoreSight, these debug components are provided on a dedicated bus, the debug APB. This ensures a clear separation between system memory space and debug memory space. An exception is the Cortex-M processors where a shared AHB interconnect supports both system memory and debug access as an area-reduction trade-off.

An on-chip agent must first navigate the system memory bus before being multiplexed with the DAP initiated transactions on the Debug APB. This provides two memory mapped views, one from the external debugger and one from the on-chip agent. Both views share access to the debug  components using the same address offsets within the mapped regions. The system view of the debug APB will typically have a non-zero base address whilst the external debugger view uses a base address of zero.

The upper address bit (PADDRDBG31) is only accessible from the external debugger and serves as an access control mechanism.

Debug Memory Discovery and ROM Table Entries

Every CoreSight component with an APB memory map occupies one or more 4kB blocks of memory. Within this block, CoreSight defines the content of some discovery registers. You can see the CoreSight TRM on ARM Infocenter for each individual component for specific details. The discovery pointer structure is shown in Figure 1 above, some examples of the individual registers are shown in Table 2 below.

Example CoreSight discovery registers

At least one ROM table component must be present as a slave to any AP which contains debug components. This will be the APB-AP, or AHB-AP in the case of a Cortex-M system. Each ROM table contains a list of address offsets which can be used to locate component base addresses. These components can themselves be ROM tables, but each physical component or ROM table must appear only once in the expanded list of pointers.

The AP contains a base address register which must point to the master ROM table for that bus. Typically, this will occupy the lowest 4k block of the address space. The ROM table is a CoreSight component, and contains standardized identification registers. It also contains an identifier for the SoC as a whole which can be used by debug agents to look-up against a database of known devices. This lookup can provide information about SoC specific features.

Typically the ROM table hierarchy will match the design hierarchy of modules containing debug APB. In this way, larger systems can be constructed from sub-systems and clusters. As a result, the debug APB is often sparsely populated.

If you enjoyed this blog, check out part 3 of this series by clicking on the link below.
