I'm having a hard time trying to get some data from ADC1 - Sample Sequencer 3 - AI2, of TM4C1294NCPDT.
I followed every step in the datasheet http://www.ti.com/lit/ds/symlink/tm4c1294ncpdt.pdf
But no data is get. I made the code bllow:
#include <TM4C129.h>
uint32_t valor = 0;
void ADC1SS3_Handler(void){ valor = ADC1->SSFIFO3; ADC1->ISC |= (1UL << 3);}
int main(){ //ADC1 - SS3 //PE1 - AIN2 - Analog-to-digital converter input 2 SYSCTL->RCGCGPIO |= (1UL << 5) | (1UL << 4); /* enable clock to PORT F, E */ GPIOF_AHB->DIR |= (1UL << 4); /* make PORTF4 input for switch */ GPIOF_AHB->DEN |= (1UL << 4); /* make PORTF4-0 digital pins */ SYSCTL->RCGCADC |= (1UL << 1); //Enable clock to ADC 1 GPIOE_AHB->AFSEL |= (1UL << 1); //Enable alternate function for this pin GPIOE_AHB->DEN &= ~(1UL << 1); //Make this pin an analog input GPIOE_AHB->AMSEL |= (1UL << 1); //Disable the analog isolation circuit ADC1->ACTSS &= ~(1UL << 3); //Ensure that the sample sequencer is disable ADC1->EMUX = (0xF <<12); //Selects the event (trigger) ADC1->SSEMUX3 = 0; // Clear to SSMUX3 select AI[15:0] ADC1->SSMUX3 = 2; ADC1->SSCTL3 = 0x6; ADC1->IM |= (1UL << 3); ADC1->ACTSS = (1UL << 3); ADC1->ISC |= (1UL << 3); NVIC_EnableIRQ(ADC1SS3_IRQn);
while(1){ }
}
I don't see where it's wrong.
This is all TI-specific stuff - nothing to do with Keil or ARM.
You'd be better asking on TI's forum
community.arm.com/.../158950
