I have a code that computes FFT using fftpack functions npy_rffti and npy_rfftf . I want to replace them using arm library functions. I have a real signal. I wrote the below code.
arm_rfft_fast_instance_f32 rfft_instance; arm_rfft_fast_init_f32(&rfft_instance, 1024); static float32_t *rfft_result; rfft_result = malloc(n * sizeof(float32_t)); arm_rfft_fast_f32(&rfft_instance, accel_copy, rfft_result, 0);
Below is my existing code with fftpack functions:
int len_rffti = 2*n + 15; /* 15 extra 32-bit ints used as storage in fftpack's state */ Treal* rffti = malloc(len_rffti * sizeof(Treal)); npy_rffti(n, rffti); /* calculates rffti */ int len_buf = (n/2 + 1) * 2; /* n+1 if n is odd. otherwise n+2. buf[0] is DC component and is ignored */ Treal* buf = malloc(len_buf * sizeof(Treal)); /* fill raw accel signal into buffer */ buf[0] = 0.0f; for (i = 0; i < n; i++) { buf[i+1] = (Treal) accel[i]; } /* calculate FFT. puts FFT into buffer */ npy_rfftf(n, buf+1, rffti);
Both produce very different values of FFT. What am i doing wrong? Any help is appreciated. Thanks
How, exactly, are they "different" ?
What debugging / testing / investigation have you done to find the problem(s) ?
