The rise of edge computing has brought new challenges to the world of cloud-native architecture. With applications running on both the edge and the cloud, managing and securing these distributed environments can be a complex task. Service meshes have emerged as a solution to this challenge, providing advanced traffic management, security, and observability features that are essential for effective application management in a distributed environment.
Linkerd provides an efficient service mesh solution to effectively manage and secure clusters at the edge or in the cloud. It works by injecting a lightweight proxy (sidecar) next to each service instance to handle communications between services. The proxy has a very low CPU and RAM footprint, that provides a secure and minimal latency overhead for traffic flow. Linkerd has been available on Arm64 since version 2.9, thanks to contributions and support from project maintainers and the community.
Linkerd provides a feature called multi-cluster, which enables seamless communication between services running in different Kubernetes clusters. These clusters can span multiple clouds, datacenter or edge locations. In a multi-cluster setup, Linkerd deploys a control plane in each cluster, allowing it to manage the services running within that cluster. This multi-cluster setup works by mirroring the service information between clusters. The remote services work as Kubernetes services, and hence all the observability, security and routing features apply to all these clusters. Let's look at a use case now.
Use case: Managing Distributed Services with Linkerd on Arm-based Kubernetes clusters
Here, we describe how to connect an application across a multi-cluster service mesh in a cloud to edge scenario. We deploy Linkerd multi-cluster setup running on Arm-based Kubernetes cluster in the cloud and at the edge. We also showcase features like traffic management, security, real-time monitoring of applications, global observability, traffic splitting etc. in an edge to cloud scenario. The high-level flow of the use case is as follows:
Configurations:
Pre-requisites:
Make sure both the clusters are accessible via kubectl. The figure below shows the EKS cluster and kubectl command result
We’re now ready to install Linkerd on both the clusters. Linkerd requires a shared trust anchor to exist between both of clusters in a multi-cluster setup. This encrypts the traffic between the clusters so that it’s protected and not open to internet. Install the step cli using the instructions given in this link. Use the following command to generate the root certificate for both of our clusters
step certificate create root.linkerd.cluster.local root.crt root.key \ --profile root-ca --no-password --insecure
This will form a common trust relationship between our clusters. Now, using this trust anchor let’s generate certificate for our clusters
step certificate create identity.linkerd.cluster.local issuer.crt issuer.key \ --profile intermediate-ca --not-after 8760h --no-password --insecure \ --ca root.crt --ca-key root.key
Now, let’s install Linkerd on both of our clusters. For simplicity’s sake we’ll call our EKS cluster – cloud and our edge/local cluster – edge. Run the following command to install linkerd CRDs on both clusters
linkerd install --crds | | tee \ >(kubectl --context=edge apply -f -) \ >(kubectl --context=cloud apply -f -)
Now, install the Linkerd control plane in both the clusters
linkerd install \ --identity-trust-anchors-file root.crt \ --identity-issuer-certificate-file issuer.crt \ --identity-issuer-key-file issuer.key \ | tee \ >(kubectl --context=edge apply -f -) \ >(kubectl --context=cloud apply -f -)
We’ll also install the Linkerd viz extension which install an on-cluster metric stack and dashboard
for ctx in edge cloud; do linkerd --context=${ctx} viz install | \ kubectl --context=${ctx} apply -f - || break done
After the installation, we now need to install the multi-cluster components
for ctx in edge cloud; do echo "Installing on cluster: ${ctx} ........." linkerd --context=${ctx} multicluster install | \ kubectl --context=${ctx} apply -f - || break echo "-------------" done
We’ll also need to activate the gateway component in the Kubernetes namespace – linkerd-multicluster. It’s a simple container injected with linkerd proxy. Use the following command
for ctx in edge cloud; do echo "Checking gateway on cluster: ${ctx} ........." kubectl --context=${ctx} -n linkerd-multicluster \ rollout status deploy/linkerd-gateway || break echo "-------------" done
Now, that the linkerd control plane is installed in both the clusters, we can now link the clusters and start mirroring the services. To link the edge cluster to cloud, run the following command:
linkerd --context=cloud multicluster link --cluster-name cloud | kubectl --context=edge apply -f –
Run the following command to check that the edge cluster can reach the cloud cluster and its services
linkerd --context=west multicluster check
Once it’s done successfully, we’ll add a few services that we can mirror across both the clusters. Execute the following to add two deployments – frontend and podinfo - in both the clusters in ‘test’ namespace
for ctx in edge cloud; do echo "Adding test services on cluster: ${ctx} ........." kubectl --context=${ctx} apply \ -n test -k "github.com/linkerd/website/multicluster/${ctx}/" kubectl --context=${ctx} -n test \ rollout status deploy/podinfo || break echo "-------------" done
On the edge cluster run the following command to check its status:
kubectl --context=edge -n test port-forward svc/frontend 8080
Access the URL on http://localhost:8080 and check how it looks on the edge cluster.
Now, by default all the requests are going through internet. With Linkerd we can extend the mTLS functionality across both clusters making sure that the traffic is encrypted. Run the following command to verify:
linkerd --context=edge -n test viz tap deploy/frontend | \ grep "$(kubectl --context=cloud -n linkerd-multicluster get svc linkerd-gateway \ -o "custom-columns=GATEWAY_IP:.status.loadBalancer.ingress[*].ip")"
tls=true means that the requests are being encrypted.
Linkerd also allows Failover in a multi-cluster setup. We can achieve this by using TrafficSplit. It allows us to define weights between multiple services and split traffic between them. For our clusters, let’s split the podinfo service in edge and cloud. Run the following command to split the traffic between both services. New requests to podinfo will get forwarded to the podinfo-cloud cluster 50% of time and the other 50% to local podinfo.
TrafficSplit
kubectl --context=edge apply -f - <<EOF apiVersion: split.smi-spec.io/v1alpha1 kind: TrafficSplit metadata: name: podinfo namespace: test spec: service: podinfo backends: - service: podinfo weight: 50 - service: podinfo-cloud weight: 50 EOF
Now, refreshing the URL a couple of times http://localhost:8080, should show info from both the clusters.
To see the metrics of the trafficsplit use the following command to launch a dashboard
linkerd viz dashboard
Click the following URL to see the dashboard – http://localhost:50750. We should see a response like below
Conclusion
In distributed computing environments, managing and securing communication between services can be challenging. With a service mesh, we can address these challenges by providing visibility, security, resilience, scalability etc. for a variety of cloud native workloads running on Arm-based Kubernetes clusters either in the cloud or at the edge. Linkerd provides a lightweight and efficient service mesh that focusses on cross-cluster communications with no changes to the application.
