It often surprises me how many people believe that “ARM doesn’t do division” or “ARM cores don’t have divide hardware”. Of course, that used to be the case – up until the launch of the Cortex brand in 2004, ARM cores simply didn’t have hardware support for division operations.
Well, here’s the official answer...
Support for the SDIV/UDIV instructions is mandatory in ARMv7-M and for the Thumb instruction set in ARMv7-R. It is optional for the ARM instruction set in ARMv7-R. It is optional in ARMv7-A and, if supported, may be in the Thumb instruction set only or in both Thumb and ARM. In ARMv7-A with the Virtualization Extensions, it is mandatory in Thumb and ARM.
Confused! Well, if you want to know whether your particular core supports these instructions, there is a handy register to check. On ARMv7-A and ARMv7-R cores, the Instruction Set Attribute Register (ID_ISAR0) contains a field called “Divide_instrs” (bits 27:24) which takes the following values:
Divide_instrs”
0000 – Not implemented 0001 – SDIV/UDIV in Thumb instruction set 0010 – SDIV/UDIV in both ARM and Thumb instruction sets
You can find more information in the Architecture Reference Manuals.
The following table shows the status of hardware divide support for all current ARM cores.
The syntax of the instructions is simple enough:
SDIV Rd, Rn, Rm ; Rd = Rn / Rm
The only real wrinkle you need to be aware of is the handling of division by zero. Again, the behavior varies by architecture.
ARMv7-A - divide by zero always returns a zero result.
ARMv7-R - the SCTLR.DZ bit controls whether you get a zero result or a Undefined Instruction exception when you attempt to divide by zero (the default is to return zero).
SCTLR.DZ
ARMv7-M - the CCR.DIV_0_TRP bit controls whether an exception is generated. If this occurs, it will cause a UsageFault and the UFSR.DIVBYZERO bit will indicate the reason for the fault.
CCR.DIV_0_TRP
UFSR.DIVBYZERO
Note that none of the divide instructions, in any of the architectures, affect the condition code flags. All can be made conditional: in ARM state, via the condition code field and in Thumb state via the IT instruction.
So, many ARM cores do support hardware divide these days. But there are still some which don’t. So we should consider what happens there.
In the general case, the compiler will use a run-time library routine for division and you should regard this as “slow”. The ARM tools do provide two versions of the library routine, one of which is labelled “real-time” and is guaranteed to return in fewer than 45 cycles every time. It will be faster for larger quotients but slower for typical quotients so should be used in applications which require a more deterministic division performance.
The compiler will, however, do its best to provide the best division performance it can. In the case of division by a compile-time constant, it will use shifts where possible to divide by power of two, for instance. For other constants, it will use an inline long multiplication sequence to calculate an integer result. For example, here is the sequence it will use for division by ten.
LDR r0, =0xCCCCCCCD UMULL r2, r1, r0, r1 MOV r1, r1, LSR #3
The constant used is a fixed-point binary representation of 1/10. The final shift removes the fractional part of the result to leave an integer.
And don’t forget that the module (%) operator requires a division to work out the remainder, so is really a “divide in disguise”. A common requirement is to increment a counter and wrap it a limit value. Programmers often use a module to do this. The code below shows that a simple test-and-reset construct is much more efficient.
count = (count + 1) % 60;
ADD r1, r0, #1
MOV r0, #0x3c
BL __aeabi_idiv
MOV r0, r1
if (++count >= 60)
count = 0;
ADD r0, r0, #1
CMP r0, #0x3c
MOVCS r0, #0
So far, we have only discussed integer arithmetic. Many applications running on ARM platforms require floating point support.
Many ARM cores support floating point hardware as an option. This applies across the range from the Cortex-M4 microcontroller to the Cortex-R and Cortex-A cores. In many cases, the support is optional so you should check documentation to find out what is supported in your device.
Be careful though and check carefully. The VFP architecture supports single and double precision floating point, including divide operations. The NEON architecture (the two are often implemented together and share a register bank) only supports single precision floating point and doesn’t support division. In these cases, a runtime library would he used.
[CTAToken URL = "https://developer.arm.com/products/processors" target="_blank" text="Learn more about Arm cores" class ="green"]
Peter:1. it is ALWAYS wrong because there is no precondition about the initial value of count, in the example if count value is 358 after 1 increment the result is 0 as if value was 300 but obviously in the 1st case you should require just one more step (after the first preincrement) because the boolean test become true but because the logic behind it it is wrong you will require 60 increments more.
And I would not tell about which programmer should use module to limit a value because at least in C and C++ any decent software engineer doesn't use module for that. May be we have different idea about what means decent and expert engineer.
2. How many engineers don't know that module is the operator returning the rest of a division? I hope very few. Seems to me that to compute module (without a hardware divider) we need a division and not only a division. I am not sure if in Mathematics in English module operator is colled module or remainder but I think any high school student have the notion of module.
3. The article had been more concrete and helpful just pointing to the complexity of the division algorithm in ARM assembly (traditional, thumb and thumb-2) and remembering somethink about the modulo and its mathematical expression requiring 1 division, 1 multiplication and 1 subtraction. There is nothing more to say.
Anyway I turn back to my initial problem because googling I found the article: correcting the result of a division by zero operation without resetting the cpu.
but in both cases the other code only returns 0 so it is totally wrong
As per the sentence above the table, this isn't designed to be a generate purpose replacement for every use of modulo.
"A common requirement is to increment a counter and wrap it a limit value. Programmers often use a modulo to do this. The code below shows that a simple test-and-reset construct is much more efficient."
Did you actually try to run it? Note the pre-increment on "count" in the "if" test - the counter will increment on every iteration.
The code using modulo operator and the greater or equal are not equivalent. % returns the rest of a division by a number so 125 % 60 = 5 as 305 % 60 but in both cases the other code only returns 0 so it is totally wrong.
Mathematically:
C = A % B is equivalent to C = A – B * (A / B)
and that is the only general way to compute the modulo.
Just in case B is a power of 2 you can simplify the equivalence, in that case and only in that case:
C = A%B is equivalent to C = A & (B-1)
Thanks for the comment, Pete. Good point which extends to an area I didn't want to get in to in a first pass. It would be good to see an example of you to use those instructions to implement an iterative division operation.
